• Photos and sketches are placed before the step they

refer to. Frequently you can study photos in following steps

to get another view of the same parts.

• The stabilizer and wing incidences and engine thrust

angles have been factory-built into this model. However,

some technically-minded modelers may wish to check

these measurements anyway. To view this information visit

the web site at www.greatplanes.com and click on

“Technical Data.” Due to manufacturing tolerances which

will have little or no effect on the way your model will ﬂy,

please expect slight deviations between your model and

the published values.

• The Edge 540 1.60 ARF is factory-covered with Top Flite

MonoKote

ﬁlm. Should repairs ever be required, MonoKote

can be patched with additional MonoKote purchased

separately. MonoKote is packaged in six-foot rolls, but

some hobby shops also sell it by the foot. If only a small

piece of MonoKote is needed for a minor patch, perhaps a

fellow modeler would give you some. MonoKote is applied

with a model airplane covering iron, but in an emergency a

regular iron could be used. A roll of MonoKote includes full

instructions for application. Following are the colors used

on this model and order numbers for six foot rolls.

Yellow (TOPQ0203)

White (TOPQ0204)

Missile Red (TOPQ0201)

Metallic Blue (TOPQ0402)

ORDERING REPLACEMENT PARTS

Replacement parts for the Edge 540 1.6 ARF are available

using the order numbers in the Replacement Parts List that

follows. The fastest, most economical service can be provided

by your hobby dealer or mail-order company.

To locate a hobby dealer, visit the Great Planes web site

at www.greatplanes.com. Choose “Where to Buy” at the

bottom of the menu on the left side of the page. Follow the

instructions provided on the page to locate a U.S., Canadian

or International dealer.

Parts may also be ordered directly from Hobby Services by

calling (217) 398-0007, or via facsimile at (217) 398-7721,

but full retail prices and shipping and handling charges will

apply. Illinois and Nevada residents will also be charged

sales tax. If ordering via fax, include a Visa

or MasterCard

number and expiration date for payment.

Mail parts orders and payments by personal check to:

Hobby Services

3002 N. Apollo Drive, Suite 1

Champaign, IL 61822

Be certain to specify the order number exactly as listed in

the Replacement Parts List. Payment by credit card or

personal check only; no C.O.D.

If additional assistance is required for any reason, contact

Product Support by telephone at (217) 398-8970, or by

e-mail at [email protected].

REPLACEMENT PARTS LIST

Order Number Description How to Purchase

Missing pieces ....Contact Product Support

Instruction manual Contact Product Support

Full-size plans ........................Not available

Contact your hobby supplier for the following parts:

GPMA3080 ...... Wing Set

GPMA3081 ...... Fuselage

GPMA3082 ...... Tail Set

GPMA3083 ...... Cowl

GPMA3084 ...... Canopy

GPMA3085 ...... Landing Gear

GPMA3086 ...... Wheel Pants

GPMA3087 ...... Decal

GPMA3088 ...... Canopy/Hatch

GPMA3089 ...... Spinner
